Summer Offers UK Ship KEYDIY KD-X4 Key Programmer Combine KD Max, KD Mate, KD Mini Prog 5-in-1 Newly Add MQB48 MQB49 5C 5D, MLB, BMW BDC2/ BDC3

Product Description

KEYDIY KD-X4 Key Programmer Free with DB25 Key Programming Cable

• For BMW G Series BDC2 add key with BDC2 adapter
• For VAG MQB/MLB Add key no removing cluster with KD-MP tool
• For BMW G chassis BDC3 add key function. No need access to the vehicle, get data from original key. (Need generate KD FGB23/ KD FGB57 remotes)
• For MQB49 5C 5D Key Adding
• Newly support for Jaguar and Land Rover models manufactured after 2018
• It supports key programming without disassembling the KVM module or going through online programming, and no code tracking
• It works with original factory keys and KD ZB keys

• VW MQB49/5C Key Adding
• VW/Audi 5D Key Adding
• Porsche 5D Key Adding
• BMW BDC/BCP No-disassembly Key Adding (Including the LCD key)

• Rolls-Royce No-disassembly Key Adding
• Toyota SUPRA No-disassembly Key Adding

• Industry debut UWB (Bluetooth) key detection
• Industry exclusive Toyota used key unlock free programming
• First to release MLB chip detection function
• CANFD integration, no other accessories required
• 24V Chinese heavy-duty truck model programming
• Built in programmer function, will support 5A mileage function
• One second startup, greatly improves locksmith's work efficiency
• Language: English, Vietnamese, Russian, French, Spanish, German, ltalian, Arabic, Thai, Japanese, Korean, Simplifed Chinese
• One wire harness can cancel Ford alarm and program the Toyota 8A blade key all key lost situation (Need to purchase separately)
• 2018-2024 Jaguar and Land rover smart key programming (JPLA / K8D2 / J9C3 / M9R3 systems)
• Full BDC2 / BDC3 Key Cloning:  LCD & U-Chassis BCP supported. After activating MQB & BMW-G, key adding is permanently FREE. Supported up to 2026. MQB & BMW-G functions permanently FREE.
• Free Download KEYDIY KD-X4 User Manual

• Yamaha ID47/ID49 motorcycle key barcode retrieval function
• Toyota, Hyundai Kia smart key programming
• Detect 868MHZ and 902MHz frequency remote detection
• Detect MLB Key
• Detect Bluetooth Key
• Suzuki/Honda motorcycle read PIN Code

• Remote Generation:
  Supports over 5600 remote control programs, enabling quick and versatile remote creation.

• Toyota Rolling-Code & MQB Key Programming:
  Supports Toyota 2019+ models with rolling-code bypass and VW/Audi MQB key programming.

• Remote Copying:
  Compatible with 50+ vehicle brands for easy cloning and duplication of remotes.

• Key Simulation:
  Simulates both standard remotes and smart keys for testing and verification.

• Frequency Detection:
  Detects 315M, 433M, 467M, 868M, 902M, and 2.4G frequencies for accurate diagnosis.

• Transponder (Chip) Recognition:
  Supports a wide range of chips including MLB, 5C, 46, 47, 48, MOB48, 4D, 4C, 8A, 6A, 4A, 8E, 8C, 13, 11, 12, 7935X, 49, and 33/40–44 AUDI5 ID card/IC card.

• Specialized Chip Generation:
  Generates Toyota G, NB multifunction, 30/40–44, 48, 4D/4C, Toyota 8A/H, and 46 series specialized chips.

• Chip Data Acquisition:
  Supports built-in, external, and antenna-based data collection methods — ideal for BYD all-key-lost, OBD 48, and similar scenarios.

• Key Unlocking:
  Unlocks keys from 36 different brands, enabling re-use of used keys.

• Battery Voltage Detection:
  Tests 3V remote key battery voltage to ensure stable performance.

• Key Leakage Detection:
  Identifies current leakage issues in 3V remotes to prevent malfunction.

• Used Remote Programming (No Unlock Required):
  Directly programs used Toyota/Lexus 8A-AA, BA, 4A type keys without unlocking.

• IMMO Programming:
  Supports 51+ car brands, with ongoing updates for newer models.

• Programmer Function:
  Reads IMMO data from VW/Audi MQB dashboards for advanced immobilizer work.

KD X4 Button and Interface Introduction:
1. Power on/off button:
In the shutdown state, press and hold the power button for 2 seconds to turn on the device.
When the device is turned on, press and hold the power button for 2 seconds to turn it off.

2. Chip recognition button:
Press the chip recognition button to enter the chip detection function; long-press the chip recognition button to enter the function switching menu, where you can select chip recognition, ignition coil detection, and system settings functions.

3. Remote copy button:
Press and hold the remote copy button to enter the remote normal copy function. Long-press the remote copy button to enter the function switching menu, where you can select the normal copy, special copy, and remote data comparison functions.

4. Frequency detection button:
Press and hold the frequency detection button to enter the frequency detection mode within 1GHz. Press and hold the frequency detection button to enter the function switching menu, where you can select frequency detection within 1 GHz, 2.4 GHz frequency detection, or battery voltage detection/leakage detection.

5. Key induction coil and immo chip placement hole:
Used for identifying and copying car key immo chips, and can also be used for wireless generation of KD remotes.

6. Frequency detection area:
Place the key in the frequency detection area and press the key remote control button to detect the remote control frequency.

7. Power indicator light:
Used for power on and charging status indication, power on status: indicator light flashes; Charging status: The indicator light is constantly on and turns yellow; Fully charged state: The indicator light is constantly on and turns green.

8. Display screen:
It can display device information and key information, etc.

9. USB interface:
Used for charging, wired connection to mobile phones or PC terminals.

10. Programmer interface:
Used for programmers to read data from Volkswagen MQB dashboard, Audi dashboard or BCM data, as well as various octagonal chip EEPROM data reading and writing.

11. Wired programming interface:
Used for KD wired remote generating, unlocking with original keys, remote battery voltage detection, and leakage detection.

12. Collecting antenna:
It is used for collecting data on car ignition, testing ignition coils, chip simulation, and other functions.

13. External acquisition antenna interface:
It is used for collecting car ignition data, ignition coil detection, chip simulation, and other functions.

14. Toyota adapter cable interface:
Toyota/Lexus smart key all key lost cable interface.

15. OBD main cable interface:
Connect the external OBD 15 cable to the car, connect the Mobile KD APP, and enter the programming function for use.
